PETG/PET shrink shirnk film to repalce PVC good for printing thermo shrink film

PETG Film Features

• High gloss
• High Transparency. High-impact strength.
• Suitable for rotogravure, flexo graphic, rotary offset&digital printing.
• Excellent process ability during printing, tube forming & shrinking
• Simple& multiple contours, high shoulder& narrow neck configurations.
• Thickness 30-60 mic. Shrinkage TD 50-80%

PETG Film Description

PETG film is the world well-known environmental friendly shrinkable material. Its technical index, physical performance, application arrange and method is close to PVC shrinkable film. PETG shrinkable film is the most advanced one direction shrink film. PETG TD shrinkable film has superior printability and high transparency, excellent performance in transverse direction shrinkage. Widely applications in the package of normal shape and extraordinary shape bottles. Very suitable for different printing process and labeling machine.

Item

Value

Product model

Middle shrinkage rate(T0560)

High shrinkage rate(T0575)

Extreme high shrinkage rate(T0580)

Material

PETG

Density

1.32±0.02

Thickness tolerance

±2μm

Width tolerance

+0~3mm

End surface tolerance

≤2mm

Light transmittance

≥90%

Haze

≤4.0%

Dynamic friction coefficient

Inner surface

0.35^+0.1_-0.05

Outer surface

0.35^+0.05_-0.05

Tensile strength

MD

≥40Mpa

TD

≥150Mpa

Elongation at break

MD

≥300%

TD

≥40%

Shrinkage(100℃ water bath,10sec)

MD

5⁺⁵_-2

5⁺⁵_-2

5⁺⁵_-2

TD

60⁺⁵_-5

75⁺⁵_-5

≥80

Shrinkage(85℃water bath,10sec)

MD

0⁺³_-5

0⁺³_-5

0⁺³_-5

TD

50⁺⁵_-5

65⁺⁵_-5

70⁺⁵_-5

Jinghong Company Profile

JiangSu Jinghong New Material Technology Company, formerly known as Suqian Jinghong Color Printing&Packing Co.,Ltd, was established in August 2001. Our company, covering an area of 330,000 square meters, is located in the Hi-tech Industrial Development Zone in the city of Suqian that is the hometown of King Xiangyu and situated on the beautiful bank of the Great Canal. Our main businesses include the PETG polyester chip, PETG shrink film, battery label and medical labels. We are a professional scientific enterprise with a complete industrial chain featuring the special polyester chip synthesis, PETG shrink film production and label making. Our products are favored by many top international companies, such as Duracell, Spectrum Brands, Energizer, Panasonic, Nanfu Battery Co., Ltd, Sichuan Changhong New Energy Technology Co., Ltd and so on, which helps us create an extensive sales network at home and abroad. Jinghong serves the society by its high quality services and products in a way to contribute to the society’s well-being by its sincere actions.

Jinghong Other products

• PETG resin/granules,
• PETG high/middle shrink film
• PETG/PVC battery labels
• PET release film
• PETG/PVC self-adhesive material
